Definetion of Die Casting

Die casting is a metal casting process that is characterized by forcing molten metal under high pressure into a mold cavity. The mold cavity is created using two hardened tool steel dies which have been machined into shape and work similarly to an injection mold during the process.

Most die castings are made from non-ferrous metals, specially

  • Zink
  • Copper
  • Aluminium
  • Magnesium
  • Lead
  • Pewter : 85-99% tin along with copper, antimony, bismuth
  • Tin based alloy

Casting

Casting is a manufacturing process by which a liquid material is usually poured into a mold, which contains a hollow cavity of the desired shape, and then allowed to solidify. The solidified part is also known as a casting, which is ejected or broken out of the mold to complete the process.
Core Cadd Solutions provide professional training in design. Our Training & Services design such that, fresher can easily make their career in design. Our Trainer are highly experienced in same Domain

Topic

  • Introduction about die design.
  • Study about input data.
  • Selection of tool.
  • Conceptional tool layout.
  • Model QC.
  • Feasibility checking.
  • Draft analysis and its standard.
  • Radius analysis and its standard.
  • Parting line concept.
  • Type of die selection
  • Wall thickness feasibility.
  • Machine selection.
  • Tool design calculation.
  • Die splitting.
  • Side core splitting and designing.
  • Slide stock selection.
  • Cylinder standard.
  • Feeding system.
  • Ejection system.
  • Design of mold base.
  • Other part of tool design.
  • Assembly.
